Technical specification & Dimensions (mm)

Technical specification

Engine	RWD (225 bhp)	AWD Dual Motor (320 BHP)
	DRIVETRAIN
Max. power, bhp at rpm	225, 4600-9200	320, 4600-9200
Max. torque, Nm at rpm	350, 0-4400	605, 0-4400
1 speed automatic transmission	✓	✓
	SUSPENSION & TYRES
Front suspension	MacPherson Multi-Link
Rear Suspension	Multi link
19" tyres	235/55R19	235/55R19
20" tyres	255/45R20	255/45R20

Engine	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	BATTERY PACK
Battery	84.0kWh Li-ion polymer battery
Electric Motor Type	Permanent Magnet Synchronous Motor
Max Battery Power (kW)	277	277
Number of Cells	384	384
Nominal Voltage (V)	697	697
Capacity (Ah)	120.6	120.6
Battery Weight (kg)	476.2	476.2

Engine	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	CHARGING*
AC Charge (10-100%) - (230v / 12A)	34 hrs 40 mins	34 hrs 40 mins
AC Charge (10-100%) - (11kW 3-Phase Charger)	7 hrs 35 mins	7 hrs 35 mins
DC Charge (10-80%) - 50kw (max 125A)	1hr 16 mins	1hr 16 mins
DC Charge (10-80%) - 350kw (max 200A)	18 mins	18 mins

*In order to achieve the maximum charging speed, EV6 must use an 800 volt electric vehicle charger that delivers at least 260kW of electricity. Actual charging speed and charging time may be influenced by the battery temperature and weather conditions.

*Range figures are determined according to the standardised EU measurement procedure (WLTP). Individual driving style and other factors, such as speed, outside temperature, topography and the use of electricity-consuming devices/units, have an influence on the real life range and can possibly reduce it.

WLTP Pure Electric Energy Consumption & Range information	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	19" Wheel - Air
Max Speed (mph)	115	-
Acceleration 0-62 mph (seconds)	7.7	-
Electric Energy Consumption (Wh/km) - City	121	-
Electric Energy Consumption (Wh/km) - Combined	159	-
Range (mi) - City	475	-
Range (mi) - Combined	361	-
Carbon Dioxide (CO2) Emissions (g/km)	0	-
Noise Level Moving dB	67	-

WLTP Pure Electric Energy Consumption & Range information	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	19" Wheel - GT-Line
Max Speed (mph)	115	116
Acceleration 0-62 mph (seconds)	7.7	5.3
Electric Energy Consumption (Wh/km) - City	121	131
Electric Energy Consumption (Wh/km) - Combined	159	170
Range (mi) - City	475	443
Range (mi) - Combined	361	339
Carbon Dioxide (CO2) Emissions (g/km)	0	0
Noise Level Moving dB	67	67

WLTP Pure Electric Energy Consumption & Range information	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	20" Wheel - GT-Line S (inc. Heat Pump version)
Max Speed (mph)	115	116
Acceleration 0-62 mph (seconds)	7.7	5.3
Electric Energy Consumption (Wh/km) - City	126	139
Electric Energy Consumption (Wh/km) - Combined	169	177
Range (mi) - City	466	415
Range (mi) - Combined	347	324
Carbon Dioxide (CO2) Emissions (g/km)	0	0
Noise Level Moving dB	67	67

Engine	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	VEHICLE WEIGHT & CAPACITY INFORMATION
Gross vehicle weight (kg) (19" / 20" Wheel)	2,495	2,600
Kerb weight	2,065	2,165
Maximum braked trailer weight	1,800	1,800
Maximum tow ball weight	100	100
Luggage compartment capacity, rear seats upright, litres (W/O premium Sound/W Premium sound)	490 / 480	490 / 480
Luggage compartment capacity, Front	52	20
Minimum turning circle (m)	11.62	11.62

Engine	RWD (225 bhp)	AWD Dual Motor (320 bhp)
	VEHICLE INSURANCE GROUPS
Air	TBC	TBC
GT-Line	TBC	TBC
GT-Line S	TBC	TBC
	SERVICE INTERVALS
	TBC

The new Kia EV6 'GT-Line & GT-Line S'

The new Kia EV6 'Air'

Kia Warranty
Over the years, Kia has become one of the most successful car manufacturers in Europe. The key to our success? We give our customers that little bit extra: better service by qualified technicians, regular product innovation and superior warranty coverage.
7 Year vehicle warranty
Our high quality standards are what make superior warranty coverage possible: 3 years / unlimited mileage and 4-7 years / 100,000 mile manufacturer's warranty. For full warranty coverage including terms and exclusions please refer to your Kia dealer.
12 Year anti-perforation warranty
Your EV6 comes with a 12 year/ unlimited mileage anti-perforation warranty. A body work inspection is required every two years, for which a charge may apply.
