Technical specification

Engine	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	DRIVETRAIN
Cubic Capacity	1,598	1,598	1,598	1,598	1,598
Max. Power, bhp at rpm	157 / 5,500	157 / 5,500	212 / 5,500	212 / 5,500	248 / 5,500
Max. Torque, Nm at rpm	264 / 3,500	264 / 3,500	350 / 3,500	350 / 3,500	350 / 3,500
6 Speed Manual	✔	-	-	-	-
7 Speed Auto Dual-Clutch Transmission (DCT)	-	✔	-	-	-
6 Speed Auto (6AT)	-	-	✔	✔	✔

Request an appointment

View Offers

	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	Powertrain
'2'	✔	-	-	-	-
'GT-Line'	✔	✔	✔	-	✔
'3'	✔	✔	✔	-	✔
'Shadow'	-	-	✔	-	-
'GT-Line S'	-	✔	✔	✔	✔
	Suspension and Tyres
Front Suspension	Macpherson Strut
Rear Suspension	Multi Link (4-Link)
17" Tyres	215/65R17	-	-	-	-
18" Tyres	235/55R18	235/55R18	235/55R18	235/55R18	-
19" Tyres	235/50R19	235/50R19	-	-	235/50R19

	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	Fuel
Fuel Type	Petrol	Petrol	Petrol	Petrol	Petrol
Fuel Tank Capacity, Litres	54	54	52	52	42
	Battery Pack
Battery	-	-	1.49kWh Li-ion polymer battery	1.49kWh Li-ion polymer battery	13.8 kWh Li-ion polymer battery
Hybrid Type	-	-	TMED	TMED	TMED
Max Power (kW)	-	-	44.2	44.2	66.9
Number of Cells	-	-	72.0	72.0	96.0
Nominal Voltage (V)	-	-	270.0	270.0	360.0
Capacity (Ah)	-	-	5.5	5.5	38.3
Battery Weight (Kg)	-	-	37.5	37.5	140.0

	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	Regulated emissions
Carbon Monoxide (mg/km)	255.40	417.00	126.50	122.70	106.30
Total Hydrocarbons (mg/km)	20.80	30.30	12.40	14.10	12.60
Nitrogen Oxide (mg/km)	9.70	20.00	15.90	13.30	5.40
Total Hydrocarbons + Nitrogen Oxide (mg/km)	-	-	-	-	-
Particulate Matter (mg/km)	0.20	0.11	0.21	0.23	0.42
	Charging
3-Pin AC Charger (10% - 100%)	-	-	-	-	5h 27m
Type 2 AC Charger (10% - 100%, 7.2 kW)	-	-	-	-	1h 45m

Test Drive Sportage

WLTP fuel consumption, emissions and performance information**	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	17" Wheel '2' Grade
Maximum Speed (mph)	120	-	-	-	-
Acceleration 0-62 mph (Seconds)	9.9	-	-	-	-
Fuel Consumption - Low MPG (l/100km)	34.0(8.3)	-	-	-	-
Fuel Consumption - Medium MPG (l/100km)	45.6 (6.2)	-	-	-	-
Fuel Consumption - High MPG (l/100km)	50.4 (5.6)	-	-	-	-
Fuel Consumption - Extra High MPG (l/100km)	42.2 (6.7)	-	-	-	-
Fuel Consumption - Combined MPG (l/100km)	43.5 (6.5)	-	-	-	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	-
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	-
Regulated Emission Standard	Euro 6E	-	-	-	-
Carbon Dioxide (CO2) Emissions (g/km)	147	-	-	-	-
Noise Level Moving/Stationary (dB)	68 / 76	-	-	-	-

WLTP fuel consumption, emissions and performance information**	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	19" Wheel GT-Line (18" on HEV)
Maximum Speed (mph)	120	119	115	-	115
Acceleration 0-62 mph (Seconds)	9.9	9.4	8.4	-	8.4
Fuel Consumption - Low MPG (l/100km)	33.6 (8.4)	37.2 (7.6)	54.3 (5.2)	-	-
Fuel Consumption - Medium MPG (l/100km)	44.8 (6.3)	47.9 (5.9)	70.6 (4.0)	-	-
Fuel Consumption - High MPG (l/100km)	49.6 (5.7)	51.4 (5.5)	57.6 (4.9)	-	-
Fuel Consumption - Extra High MPG (l/100km)	41.5 (6.8)	42.2 (6.7)	38.2 (7.4)	-	-
Fuel Consumption - Combined MPG (l/100km)	42.8 (6.6)	44.8 (6.3)	49.6 (5.7)	-	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	235.4 (1.2)
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	185
Regulated Emission Standard	-	-	-	-	40.3
Carbon Dioxide (CO2) Emissions (g/km)	Euro 6E	Euro 6E	Euro 6E	-	Euro 6E
Noise Level Moving/Stationary (dB)	68 / 76	67 / 78	68 / 76	-	68 / 75

WLTP fuel consumption, emissions and performance information**	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	18" Wheel '3' Grade
Maximum Speed (mph)	120	119	115	-	115
Acceleration 0-62 mph (Seconds)	9.9	9.4	8.4	-	8.4
Fuel Consumption - Low MPG (l/100km)	33.6 (8.4)	37.2 (7.6)	54.3 (5.2)	-	-
Fuel Consumption - Medium MPG (l/100km)	44.8 (6.3)	48.7 (5.8)	70.6 (4.0)	-	-
Fuel Consumption - High MPG (l/100km)	49.6 (5.7)	51.4 (5.5)	56.5 (5.0)	-	-
Fuel Consumption - Extra High MPG (l/100km)	41.5 (6.8)	42.2 (6.7)	38.2 (7.4)	-	-
Fuel Consumption - Combined MPG (l/100km)	42.8 (6.6)	44.8 (6.3)	49.6 (5.7)	-	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	235.4 (1.2)
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	185
Range (mi) - Combined	-	-	-	-	40.3
Regulated Emission Standard	Euro 6E	Euro 6E	Euro 6E	-	Euro 6E
Carbon Dioxide (CO2) Emissions (g/km)	149	142	129	-	27
Noise Level Moving/Stationary (dB)	68 / 76	67 / 78	67 / 76	-	67 / 75
18"/ 19" Wheel ‘Shadow’	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
Maximum Speed (mph)	TBC	TBC	115	-	-
Acceleration 0-62 mph (Seconds)	TBC	TBC	8.4	-	-
Fuel Consumption - Low MPG (l/100km)	TBC	TBC	53.3 (5.3)	-	-
Fuel Consumption - Medium MPG (l/100km)	TBC	TBC	70.6 (4.0)	-	-
Fuel Consumption - High MPG (l/100km)	TBC	TBC	56.5 (5.0)	-	-
Fuel Consumption - Extra High MPG (l/100km)	TBC	TBC	38.2 (7.4)	-	-
Fuel Consumption - Combined MPG (l/100km)	TBC	TBC	49.6 (5.7)	-	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	-
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	-
Range (mi) - Combined	-	-	-	-	-
Regulated Emission Standard	TBC	TBC	Euro 6E	-	-
Carbon Dioxide (CO2) Emissions (g/km)	TBC	TBC	129	-	-
Noise Level Moving/Stationary (dB)	TBC	TBC	67 / 76	-	-
19" Wheel GT-Line S (18" on HEV)	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
Maximum Speed (mph)	-	119	115	115	115
Acceleration 0-62 mph (Seconds)	-	9.4	8.4	8.7	8.4
Fuel Consumption - Low MPG (l/100km)	-	36.7 (7.7)	47.9 (5.9)	38.2 (7.4)	-
Fuel Consumption - Medium MPG (l/100km)	-	47.9 (5.9)	68.9 (4.1)	52.3 (5.4)	-
Fuel Consumption - High MPG (l/100km)	-	51.4 (5.5)	56.5 (5.0)	53.3 (5.3)	-
Fuel Consumption - Extra High MPG (l/100km)	-	41.5 (6.8)	38.2 (7.4)	37.2 (7.6)	-
Fuel Consumption - Combined MPG (l/100km)	-	44.8 (6.3)	48.7 (5.8)	44.1 (6.4)	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	235.4 (1.2)
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	188
Range (mi) - Combined	-	-	-	-	39.7
Regulated Emission Standard	-	Euro 6E	Euro 6E	Euro 6E	Euro 6E
Carbon Dioxide (CO2) Emissions (g/km)	-	144	132	146	28
Noise Level Moving/Stationary (dB)	-	67 / 78	67 / 76	67 / 76	67 / 75

WLTP fuel consumption, emissions and performance information**	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	18"/ 19" Wheel ‘Shadow’
Maximum Speed (mph)	120	119	115	-	-
Acceleration 0-62 mph (Seconds)	9.9	9.4	8.4	-	-
Fuel Consumption - Low MPG (l/100km)	33.6 (8.4)	37.2 (7.6)	53.3 (5.3)	-	-
Fuel Consumption - Medium MPG (l/100km)	44.8 (6.3)	48.7 (5.9)	70.6 (4.0)	-	-
Fuel Consumption - High MPG (l/100km)	49.6 (5.7)	51.4 (5.5)	56.5 (5.0)	-	-
Fuel Consumption - Extra High MPG (l/100km)	41.5 (6.8)	42.2 (6.7)	38.2 (7.4)	-	-
Fuel Consumption - Combined MPG (l/100km)	42.8 (6.6)	44.8 (6.3)	49.6 (5.7)	-	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	-
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	-
Range (mi) - Combined	-	-	-	-	-
Regulated Emission Standard	Euro 6E	Euro 6E	Euro 6E	-	-
Carbon Dioxide (CO2) Emissions (g/km)	TBC	TBC	129	-	-
Noise Level Moving/Stationary (dB)	68 / 76	67 / 78	67 / 76	-	-

WLTP fuel consumption, emissions and performance information**	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	19" Wheel GT-Line S (18" on HEV)
Maximum Speed (mph)	-	119	115	115	115
Acceleration 0-62 mph (Seconds)	-	9.4	8.4	8.7	8.4
Fuel Consumption - Low MPG (l/100km)	-	36.7 (7.7)	47.9 (5.9)	38.2 (7.4)	-
Fuel Consumption - Medium MPG (l/100km)	-	47.9 (5.9)	68.9 (4.1)	52.3 (5.4)	-
Fuel Consumption - High MPG (l/100km)	-	51.4 (5.5)	56.5 (5.0)	53.3 (5.3)	-
Fuel Consumption - Extra High MPG (l/100km)	-	41.5 (6.8)	38.2 (7.4)	37.2 (7.6)	-
Fuel Consumption - Combined MPG (l/100km)	-	44.8 (6.3)	48.7 (5.8)	44.1 (6.4)	-
Fuel Consumption - Weighted Combined MPG (l/100km)	-	-	-	-	235.4 (1.2)
Electric Energy Consumption (Wh/km) (Weighted)	-	-	-	-	188
Range (mi) - Combined	-	-	-	-	39.7
Regulated Emission Standard	-	Euro 6E	Euro 6E	Euro 6E	Euro 6E
Carbon Dioxide (CO2) Emissions (g/km)	-	144	132	146	28
Noise Level Moving/Stationary (dB)	-	67 / 78	67 / 76	67 / 76	67 / 75

	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	Vehicle Weight and capacity information
Gross Vehicle Weight (kg)	2,120	2,145	2,175	2,245	2,415
Kerb Weight (kg)	1,561	1,580	1,649	1,715	1,905
Gross Train Weight (kg)	3,630	3,655	3,535	3,605	3,625
Maximum Braked Trailer Weight (kg)	1,510	1,510	1,360	1,360	1,210
Maximum Tow Ball Weight (kg)	100	100	100	100	100
Luggage Compartment Capacity, Rear Seats Upright, Litres	562	562	587	587	540
Luggage Compartment Capacity, Rear Seats Folded, Litres	1751	1751	1776	1776	1715
Minimum Turning Circle (m)	10.92 ± 0.4

Grade	1.6 T-GDi 48V MT (157 BHP) 2WD	1.6 T-GDi 48V DCT (157 BHP) 2WD	1.6 T-GDi HEV (212 BHP) 2WD	1.6 T-GDi HEV (212 BHP) AWD	1.6 T-GDi PHEV (248 BHP) AWD
	Vehicle insurance groups
'2'	19E	-	-	-	-
'GT-Line'	20E	20E	22E	-	26E
'3'	20E	20E	22E	-	26E
'Shadow'	19E	19E	22E	-	-
'GT-Line S'	-	21E	24E	24E	27E
	Service intervals
All derivatives	12 Months / 10,000 Miles, whichever comes sooner
